Specifications:

Name : UP 7000 Intel® Processor N100. 8GB RAM. 64GB eMMC
SKU : UP-ADLN100-A10-0864-A11
General
Processor : Intel®Processor N100
Graphics : Intel® UHD Graphics Gen12
Memory : 8GB
eMMC / Storage : 64 GB
FPGA : Intel® FPGA Altera Max V
BIOS : UEFI
RTC : Yes
Wake-on-LAN (WoL) : Yes
Watchdog Timer : Yes
PXE : Yes
TPM : Equipped with TPM2.0
Compatible OS : Windows® 10 Enterprise LTSC 2021/Linux: Ubuntu 22.04 LTS/Kernel 5.15, Yocto 4.0
Dimension : 3.37" x 2.22" (85.6mm x 56.5mm)
Display
HDMI : 1 (HDMI 1.4b)
I/O
USB : 2 x USB 2.0 (via 10 pin wafer) 3 x USB 3.2 Gen 2 Type-A
UART : 1x UART (via 10 pin wafer)
40-pin GPIO header : yes
Connectivity
Ethernet : 1x GbE (Realtek RTL8111H CG)
Power
Power Requirement : 12V DC input
Power Supply Type : AT/ATX mode
Power Consumption (Typical) : 36w
Environmental & Certification
Cooling : Passive cooling (fanless)
Operating Temperature : 0℃～60℃
Storage temperature : -40°F ～ 176°F (-40°C ～ 80°C)
Certification : CE/FCC Class A, RoHS Compliant, REACH
Package
Net Weight : 150 grams
Gross Weight : 200 grams
Package dimension (L x W x H) : 151×92×51mm
HS Code : 8473302000
Country of Origin : Taiwan
Accessories
Accessories : 1x RTC Battery 1x Passive Heatsink
