The world's first card-sized Meshtastic® device with dual-band GPS. Built for reliable off-grid communication, MeshTracker X1 is an IP66-rated Meshtastic GPS tracker supporting 863–928 MHz frequencies. Powered by the latest Semtech LR2021 LoRa chip, it features BLE 5.0, USB-C connectivity, up to 5 days of battery life, and a compact, outdoor-ready design.

A Meshtastic Device You'll Actually Carry

SenseCAP MeshTracker X1 is designed for people who need reliable communication and location sharing beyond cellular networks—whether in the outdoors, at large events, or during emergency situations. With a truly portable form factor and rugged IP66 protection, it brings Meshtastic connectivity into everyday carry and real field use.

Ultra-Precise Dual-Band GPS Tracking

Powered by dual-band L1+L5 GNSS and a built-in barometer, MeshTracker X1 delivers more reliable positioning and altitude awareness than single-band GPS. It is also the world's first card-sized Meshtastic device with dual-band GPS.

Reliable Long-Range Communication

Tested at 915 MHz, MeshTracker X1 enables reliable communication over distances of up to 8 km in open line-of-sight conditions, keeping teams connected during outdoor adventures, events, and emergency situations.

Next-Generation LoRa Connectivity (LR2021)

Powered by Semtech LR2021, MeshTracker X1 delivers stronger RF performance with up to -141 dBm sensitivity and 2.6 Mbps FLRC data rates for faster, more reliable mesh communication, creating a foundation for future features like voice and image transmission.

Card-Sized Design, Easy to Carry

Slim and lightweight, MeshTracker X1 is designed for everyday carry during outdoor adventures. Wear it on a lanyard, attach it to a backpack, secure it to a bike bag, or simply slip it into your pocket for effortless off-grid connectivity.

Flexible Vibration & Sound Alerts

MeshTracker X1 provides flexible notification options with built-in vibration and buzzer feedback. Stay aware of incoming messages whether you're in a noisy event, riding outdoors, or exploring quiet trails where you prefer minimal distractions.

IP66 Rugged Outdoor Protection

Built with IP66-rated protection against dust and water, ensuring reliable performance in harsh outdoor environments such as rain, mud, and dusty trails.

USB-C Connectivity

Standard USB-C interface for charging, firmware updates, and debugging, designed for rugged outdoor use and everyday convenience.

Extended Battery Life

A highly integrated, card-sized form factor optimized around a high-capacity 1100mAh battery, delivering up to 5 days of runtime while remaining compact and portable for outdoor carry and off-grid communication.

Specifications:

• Main Controller: Nordic nRF52840
• LoRa: Semtech LR2021
• Frequency Range: 863–928 MHz
• Max TX Power: 22 dBm
• Wireless: Bluetooth v5.0
• LED: 1 × RGB
• Buzzer: 1 × buzzer for status indication
• Button: 1 × button for operation
• Vibration: 1 × DRV2605L
• Air Pressure Sensor:
• Range: 300–1100 hPa
• Accuracy: ±0.03 hPa
• Resolution: 0.06 Pa
• Temperature (Read from Barometer):
• Range: −40 to 85°C
• Accuracy: ±1°C
• Resolution: 0.0006°C
• IMU + Magnetometer: Not available in this model; available in a new SKU currently under development
• Battery: Rechargeable LCD battery, 1100 mAh
• Battery Life Monitoring: Periodic uplink battery level
• Charging Protocol: USB Type-C charging
• Power Input:
• Device: 5 V, 0.55 A
• Battery: 4.4 V, 220 mA
• Fully Charged Cut-off Voltage: 4.37 V
• Charging Temperature Limit: 5 to +45°C
• Antenna: Internal (GNSS/LoRa/Bluetooth)
• Communication Distance: Up to 8 km
• IP Rating: IP66
• Dimensions: 90 × 57 × 8 mm
• Device Weight: 45 g
• Operating Temperature: −20 to 60°C
• Certification: CE / FCC / RoHS / TELEC

X1 is developed to be a product series, in which NEW SKU to be launched in the future will be equipped with IMU and magnetometer.

Hardware Overview:

Hardware Diagram

X1 Diagram

Schematic of the new device under development

Application

From crowded festivals to remote mountain trails, MeshTracker X1 helps you stay connected, share locations, and coordinate with your group—even when cellular networks are unavailable or overloaded.

Recommended Use Cases：

• Hiking & Outdoor Adventures
• Stay Connected Beyond Cell Coverage

• Whether hiking through forests, exploring mountain trails, or backpacking into remote areas, MeshTracker X1 lets your group share locations and communicate when mobile coverage disappears.

Package Includes:

• 1 x Meshtracker X1
• 1 x 20cm Type-C Cable
• 1 x Leather Keychain
