Documentations:
Technical Specifications:
| Core parameters | Specific indicators | |
| Maximum Mapping Area | >1,000,000㎡ | |
| Relocation | Supports entire relocation, accuracy ±5cm | |
| Map Management | Supports mapping continuation, loading and saving | |
| Mapping and Localization mode | Primarily based on deep learning VSLAM, with optional LiDAR fusion | |
| Multi-sensor Synchronization | Hardware-level time synchronization | |
| Camera Specifications | Stereo fisheye, 60mm baseline, FOV 180°, Global Shutter, RGB | |
| Camera Frame Rate | Typical 15Hz, customisable 10/30Hz | |
| Dense Depth Camera Capability | End-to-end deep learning, >90% detection rate, <1.5% accuracy, works in strong light and weak texture environments | |
| AI Object Recognition & Segmentation | Support 18 outdoor scenes and 80 indoor scenarios, customizable upon request | |
| Maximum Tilt Angle | Optional LiDAR * | No requirement (for better 2D mapping, recommended ≤30°) |
| 2D Map Resolution | 2cm/5cm/10cm adjustable | |
| LiDAR Measures Range | Up to 40m@70% reflectivity | |
| Power Consumption | 10W (typical, excluding LiDAR) | |
| Operating Temperature | -20℃ ~ 50℃ | |
| Startup Temperature | ≥ 0℃ | |
| Storage Temperature | -20℃ ~ 60℃ | |
Package Includes:
- 1 x Waveshare 33342 AURORA S Fully Integrated AI Spatial Perception System, 180° Fisheye Colour Camera, 120° Wide Angle Stereo Depth Vision, Highly Open Platform, Plug-and-Play
Specif
Waveshare 33342 AURORA S Fully Integrated AI Spatial Perception System, 180° Fisheye Colour Camera, 120° Wide Angle Stereo Depth Vision, Highly Open Platform, Plug-and-Play
- Brand: Waveshare Electronics
- Product Code: NR-WaveS-AURORA-S-Fully-Integrated-AI
- Reward Points: 925
- Availability: In Stock
- रo 90,312.00
-
रo 77,728.00
- Price in reward points: 92533
-
- 2 or more रo 89,572.00
