• 8″ Touch Display
• HD Resolution | Multi-Point Touch | Full Color

Feature:

• 8-inch IPS capacitive touch screen with a hardware resolution of 1280 x 800.
• Adopts optical bonding technique, clearer imaging.
• Support 10-point capacitive touch control, tempered glass touch panel with 6H hardness.
• Drive LCD directly through Raspberry Pi's DSI interface with a refresh rate of up to 60Hz.
• When working with Raspberry Pi, the Raspberry Pi OS system driver is provided.
• Support Pi 4B/3B+/3A+, CM3+/4 should work with DSI cable.
• Support backlight adjusted by software.

Device & System Support:

• Raspberry Pi
• Supports Raspberry Pi OS, 10-point touch, driver required
• Supports Pi 4B/3B+/3A+, CM3/3+/4*
• * CM3/3+/4 requires extra adapter cable

IPS Display Panel

• Excellent Display Performance With 178° Wide Viewing Angle

Capacitive 10-Point Touch

• up to 10-point touch, depending on the operating system
• up to 6H hardness toughened glass panel
• Optical Bonding, display well and dustproof

Adjustable Brightness Via Software

Design Features:

Documentation:

• wiki

Package Includes:

• 1 x 8inch DSI LCD (C)
• 2 x FPC 15PIN 1.0 pitch 50mm (opposite sides)
• 1 x Screws pack
