RADXA's Orion O6 is an ARM AI Motherboard with Mini ITX formfactor

RADXA´s Orion O6 is a professional-grade Mini ITX motherboard designed for AI computing and multimedia applications. It is powered by the Cix P1 SoC and features up to 64GB LPDDR5 RAM. With comprehensive I/O options including quad display outputs, dual 5GbE ports and PCIe Gen4 expansion it delivers server-class performance in a compact form factor.

The Orion O6 is ideal for AI development workstations, edge computing nodes or e.g. high performance personal computing.

Specifications:

RADXA Orion O6 product details*

SoC: Cix P1 (6nm TSMC process)
4x Cortex®‑A720 (Big cores)
4x Cortex®‑A720 (Medium cores)
4x Cortex®‑A520 (LITTLE cores)
12MB shared L3 cache
GPU
Arm® Immortalis™ G720 MC10
Hardware Ray‑Tracing enabled
Graphic API´s:

Vulkan® 1.3
OpenGL® ES 3.2
OpenCL® 3.0

30 TOPs NPU

Precision Support: INT4 / INT8 / INT16 / FP16 / BF16 and TF32 acceleration
Memory LPDDR5
128-bit memory bus
Over 5500MT/s transfer speed
Over 100GB/s bandwidth
LPDDR5 with 8, 16, 32 or 64GB
SPI Flash
32MB SPI flash soldered
Wifi/BT
WiFi 6E and BT5.2 support via opt. WiFi module
Storage
1x 8GB eMMC onboard for ROOBI OS
1x microSD card slot
1x M.2 connector M key for NVMe with PCIe 3.0 x2 lanes
4x SATA Ports with Power Header
Display Outputs (up to 4 concurrent display outputs)
1x HDMI 2.0 up to 4k@60FPS (HDMI CEC not supported)
1x HDMI 2.1 up to 4k@60FPS

1x USB-C with DisplayPort Alt Mode
2x 4-lane MIPI DSI for MIPI LCD
1x eDP with Touch Panel support
Video Input
1x HDMI Input up to 4k@60FPS
2x 4-lane MIPI CSI or 4x 2-lane MIPI CSI
USB
1x USB 3.2 Gen 2 (10Gbps) Type-C Port + Power Delivery
1x USB 3.2 Gen 2 (10Gbps) Type-C Port + DP Alt Mode (4K@60Hz) + Power Delivery
2x USB 3.2 Gen 2 (10Gbps) Type-A
2x USB 2.0 Type-A
Network
Wireless / Bluetooth65978
1x M.2 E Key Connector for WiFi 6
LAN
2x 5GbE LAN ports
Other:
- 1x PWM fan connector
- 1x RTC Socket (CR1220 battery)
- 1x Front Panel header for Power Button / Reset Button / Status LED
Power
1x USB C PD power supply with 20V voltage support
1x Standard 24-Pin ATX Power Supply Interface
1x Dummy USB C power input with 20V voltage
Size 170mm x 170mm
Recommended operating temperature: 0 ~ 50°C
Essentials You Need
Radxa Orion O6
65W (20V/3.25A or larger) via e.g. ATX PSU, USB C PD 20V DC Power supply
Keyboard & Mouse
Monitor with HDMI input

Package Includes:

1 x RADXA Orion O6
- acrylic protector
- active cooler

RADXA Orion O6
