Bluetooth BLE 5.1 temperature and humidity sensor featuring Dialog Semiconductor DA14531 for BLE 5.1 and Sensirion SHTC3 Temperature & Humidity sensor.
Get ready to wirelessly monitor air temperature and humidity wherever you are.
Ready to use out of the box, the Pynode+ AIR is a Bluetooth BLE enabled sensor that connects seamlessly to your WiPy, GPy, LoPy4, FiPy or OEM module. Or you could even connect it to something that’s not a Pycom device as long as it runs BLE 5.1.
Pynode+ sensors are ready to use out of the box.
The kit contains the Pynode+ Air sensor and a coin cell battery.
Specifications:
- Temperature and Humidity Sensor
- Sensirion SHTC3 Temperature & Humidity sensor
- Bluetooth / BLE
- BLE Chip: Dialog Semiconductor DA14531
- Compatible with Bluetooth v5.1, ETSI EN 300, 328 and EN 300 440 Class 2 (Europe), FCC CFR47 Part 15 (US) and ARIB STD-T66 (Japan)
- Supports up to three BLE connections
- Microcontroller: 16 MHz 32-bit Arm® Cortex-M0+
- TX: 3.5 mA, RX: 2.2 mA (system currents with DC-DC, VBAT_HIGH =3 V and 0 dBm)
- Pynode+ Air Size
- Diameter: 30mm
- Height: 7.62mm
- Weight: 3g (excl. battery) and 6g (incl. battery)
- Weight in packaging: 21g
- Battery
- Panasonic CR2032 LITHIUM 3V COIN 20mm
- Power consumption
- Central role for initial configuration: avg.: 446uA and max: 1.67mA
- Peripheral and Advertising mode (1minute sleep timer): avg.: 220uA and max: 17.10mA (Gas sensor enabled)
Package Includes:
- 1 x Pynode+ Air
- 1 x coin cell battery
Pynode+ Air
- Brand: Pycom
- Product Code:NR-Pycom-Pynode-plus-Air
- Reward Points:22
- Availability:In Stock
-
रo 2,578.30
- Ex Tax:रo 2,185.00
- Price in reward points:2185
