Features:

Main:

• Size (mm):    115 (L) x 130 (W) x 45 (H)
• Weight:    0.560 kg
• Accessories supplied:    1 microphone and its hanger , 1 mounting bracket with fixing screws , power cord with fuse , User manual
• Antenna socket:    SO-239
• Antenna impedance:    50 ohms
• Multiconfiguration:    EU / U / D / PL / IN
• Number of channels:    40
• Frequency ranges:    from 26.965 MHz to 27.405 MHz
• Power supply:    13.2 V
• Microphone plug  front (6 pins)
• Compatible microphone type  Electret
• External loudspeaker jack:    ✅
• Channel display:    ✅
• S-meter  LED
• Modulation modes  AM / FM
• Volume adjustment and ON/OFF:    ✅
• Squelch  Manual squelch
• ASC:    ✅
• Channel selector  Up / down
• Mode switch:    ✅
• F / Menu function key:    ✅
• Key Beep:    ✅, Switchable
• Scan:    channels
• Vox:    ✅

Transmission:

• Frequency allowance:    ± 300 Hz
• Carrier power:    4 W (AM/FM)
• Transmission interference:    < 4 nW (-54 dBm)
• Audio response:    300 Hz to 3 kHz
• Emitted power in the adj. channel:    < 20 μW
• Microphone sensitivity:    3 mV
• Drain:    < 2 A (13.2 V)
• Modulated signal distortion:    2%

• Max. sensitivity at 20 dB sinad:    0.5 µV - 113 dBm (AM) / 0.35 µV - 116 dBm (FM)
• Frequency response:    300 Hz to 3 kHz
• Adjacent channel selectivity:    60 dB
• Maximum audio power:    3 W
• Squelch sensitivity:    min. 0.2 μV - 120 dBm / max. 1 mV - 47 dBm
• Frequency image rejection rate:    60 dB
• Intermediate frequency rej. rate:    70 dB
• Drain:    180 ~ 500 mA (13.2 V)

• Manual
• Datasheet
• Declaration of conformity

Package Includes:

• 1 X microphone and its hanger
• 1 X mounting bracket with fixing screws
• 1 X power cord with fuse
• 1 XUser manual
