ESP32-C3-DevKitM-1 is an entry-level development board based on ESP32-C3-MINI-1, a module named for its small size. This board integrates complete Wi-Fi and Bluetooth LE functions.
Most of the I/O pins on the ESP32-C3-MINI-1 module are broken out to the pin headers on both sides of this board for easy interfacing. Developers can either connect peripherals with jumper wires or mount ESP32-C3-DevKitM-1 on a breadboard.
Specifications:
- ESP32-C3FN4 embedded, 32-bit RISC-V single-core processor, up to 160 MHz
- 384 KB ROM
- 400 KB SRAM
- 8 KB RTC SRAM
- 4 MB SPI flash
- Operating Voltage/Power supply: 3.0~3.6 V
- Operating Temperature Range: –40~85°C
Documentations:
Warranty: 90 days
- Warranty will not apply if product fails or is damaged after delivery to you due to accident, abuse or misuse.
Package Includes:
- 1 x ESP32-C3-DevKitM-1 Development Board
