The ADC32RF55 evaluation module (EVM) is a platform for demonstrating the performance of the ADC32RF55 high-speed, JESD204B interface analog-to-digital converter (ADC). Onboard voltage regulation, clocking solution (LMK04832), transformer-coupled analog inputs, and USB interface allow for easy evaluation of the ADC32RF55.

Interfacing to the TSW14J58EVM (sold separately) via an field-programmable gate array (FPGA) mezzanine card (FMC) connector, data capture (up to 1.5 GB) of the JESD204B interface can be easily evaluated and viewed using high-speed data converter pro software (DATACONVERTERPRO-SW).

Features:

• JESD204B interface with onboard clocking solution
• Onboard power solution
• TSW14J58EVM and DATACONVERTERPRO-SW allow for easy data capture
• FMC connector allows for easy integration with FPGA development platforms

Documentations:

• Certificate
• User Guide

Package Includes:

• 1 x ADC32RF55EVM ADC32RF55 evaluation module
• 1 x Mini-USB cable
• 1 x Power cable
