9.7″ full color e-Paper display

low power, wide viewing angle, paper-like effect without electricity

Ideal for shelf labels, industrial instruments

                   Size                              Resolution                     Viewing Angle                     Display Color                  Grey Scale

                   9.7"                               1120x784                            >170°                                 E6 full color                             2

        Communication                    Display Panel                    Experience                        Environment                    Display Type

                   SPI                                    E-paper                            Paper-like              Ambient Light Required        Passively Reflective

Version Options:

                9.7inch e-Paper (E)                                         9.7inch e-Paper HAT+(E)

       Raw display, without driver board                         With e-Paper Driver HAT

Features at a glance:

• Adopts E Ink Spectra 6 (E6) technology, featuring high contrast and high color saturation
• No backlight, keeps displaying last content for a long time even when power down
• Ultra low power consumption, basically power is only required for refreshing
• Comes with online development resources and manual (e-Paper driver HAT circuit diagram, examples for Raspberry Pi / Jetson Nano / Arduino / ESP32 / STM32)
• Optional for e-Paper Driver HAT:
• Standard Raspberry Pi 40PIN GPIO header, supports Raspberry Pi and Jetson Nano series boards
• Adopts Raspberry Pi HAT+ standard to improve interoperability, helping the users to design and develop faster, easy to use with other peripherals and extend more functions for Raspberry Pi
• Adapting SPI interface for connecting with controller boards like Raspberry Pi / Jetson Nano / Arduino / ESP32 / STM32, etc.
• Onboard voltage translator, compatible with 3.3V / 5V MCUs

E Ink Spectra 6 technology

E Ink Spectra 6 is a newly launched full color e-paper technology that brings fresh vitality to the e-paper industry with excellent color performance, high resolution and high contrast.

Adopts red, yellow, and blue as the primary colors, it offers more possibilities for e-paper color display, featuring high contrast and high saturation to make images clearer and colors brighter.

More advanced performance

The resolution is up to 200ppi, features a wider range of operating temperature and faster screen refresh time. And it is more power-saving, aligning with ESG trends for energy efficiency and carbon reduction

Innovative microcup full color technology platform

Using white, red, yellow, and blue charged particles to produce six primary colors, and employing dithering technology to create vivid and saturated full color images.

Advantages of EINK

E-paper display utilizes microcapsule electrophoretic technology for displaying, the principle is: charged particles suspended in clear fluid will move to sides of microcapsule when electric field is applied, making the microcapsule become visible by reflecting ambient light, just as traditional printed paper.

E-paper display will clearly display images/texts under lamplight or natural light, requires no backlight, and features nearly up to 180° viewing angle. It is usually used as e-reader due to its paper-like effect.

Optional for e-Paper Driver HAT

Standard Raspberry Pi 40PIN GPIO header, suitable for Raspberry Pi and Jetson Nano series boards

Onboard SPI control interface

on e-Paper Driver HAT

for use with controller boards like Raspberry Pi / Jetson Nano / Arduino /

ESP32 / STM32

• PWR : Power control pin
• BUSY : Busy status output
• RST : External reset, low active
• DC : Data / Command selection (high for data, low for command)
• CS : SPI chip selection (low active)
• SCLK : SPI SCLK pin
• DIN : SPI MOSI pin
• GND :Ground
• VCC : 3.3V/5V

Application examples:

Suitable for price Tags, asset/equipment Tags, shelf labels, conference name tags.

Outline dimensions:

Resources and Services:

Documentations:

• WIKI

Package Includes:

9.7inch e-Paper (E)

• 1 x 9.7inch e-Paper (E)

                        OR

9.7inch e-Paper HAT+ (E)

• 1 x 9.7inch e-Paper HAT+ (E)
• 1 x MX1.25 9PIN cable ~20cm
• 1 x Screws pack
