TOF MINIS Laser Range Sensor:

long range | Short Blind Zone | stable/accurate/sensitive | IP68 | indoor/outdoor

Provides resources for Raspberry Pi, ESP32, Raspberry Pi Pico, Arduino, etc.

TOF (time of flight) Laser Range Sensor, front view and features

Product overview:

The TOF MINIS Range Sensor is a laser ranging sensor based on Time-of-Flight (TOF) technology. Built-in controller and ranging algorithm, providing a measurement range of up to 5m with an accuracy within ± (1% ~ 3%). Supports RS485 communication, featuring an ultra-narrow FOV and IP68 dust and water protection to effectively reduce background interference and enable longer-range, more stable distance measurement. Suitable for indoor/outdoor environments, with ambient light resistance of up to approximately 100K Lux, enabling applications such as distance measurement, robotic obstacle avoidance, path planning, ceiling detection, and material level measurement.

Specifications:

Module : TOF MINIS Range Sensor
Typical measuring range : 0.02m ~ 5m
Field of view (FOV) : 1.48°
Refresh rate : 30Hz (Supports bulk customization for higher frequency, up to 90Hz)
Ambient light tolerance : 100K Lux
Operating temperature : -20°C ~ +70°C
Operating humidity : 35% ~ 80%RH
Laser Safety Class : LASER CLASS 1 (IEC 60825-1: 2014)
Protection Rating : IP68
Wavelength : 940nm
Communication interface : RS485
Baud rate : 115200
Power supply : 4V ~ 5.6V
Power consumption : 100mW ~ 140mW
Average/Peak Current : 25mA/26mA
Weight : 15.8g
Case Material : PC
Storage temperature : -40℃ ~+80℃
Dimensions : Diameter 29.5mm, height 18.00mm
Cable length : 60cm

IP68 Protection Rating:

With a sealed standalone enclosure, effectively enhances device protection, avoids external interference, ensures a stable operating environment, and meets the demands of industrial applications

TOF (time of flight) Laser Range Sensor, long range low cost ranging module
