Multiple Inspection Scenarios: Suitable for HVAC, electrical, and industrial diagnostics, heat loss analysis, and electrical fault detection.

High Thermal Imaging Performance: Built on a 256×192 infrared sensor with AI ISP super-resolution upscaling to 512×384 for clearer thermal detail and accurate fault identification.

Temperature Measurement Range: Supports temperature measurement from –20℃ to 550℃ (–4℉ to 1022℉) with selectable low, high, and auto measurement modes.

Fixed Focus Thermal Imaging: Fixed-focus optics with a 0.3 m minimum focus distance and a 40° × 30° field of view for stable mid-range inspection.

Powered by High-Performance Hardware: High-sensitivity thermal detector (NETD <35 mK on THOR001, <40 mK on THOR002), 2-meter drop-tested housing, 25Hz fresh rate and up to 10 hours of operation.

Multi-Function Temperature Analysis: Includes emissivity, distance, and ambient compensation, isotherm analysis, temperature alarms, and shutter calibration.

Adjustable Thermal Visualization: Multiple image modes, color palettes, and 2× / 4× digital zoom for flexible thermal viewing.

Specifications:

• Model: THOR001 | THOR002
• Temperature Range:
• THOR001: ±1.5℃ or ±1.5% of the reading
• THOR002: ±2℃ or ±2% of the reading
• IR Resolution:256×192
• Super IR Resolution: 512×384
• Macro Lens: THOR001: ✔ THOR002: ×
• Lens Focal Length: 4.3mm
• Digital Zoom: 2/4×
• Display: 3.5 inch IPS（640x480）
• Point Measurement:
• THOR001: Center spot/Max/Min/6 Custom Spots/Temperature difference
• THOR002: Center spot/Max/Min/3
• Custom Spots/Temperature difference
• NETD/Thermal Sensitivity:
• THOR001: ＜35mk
• THOR002: ＜40mk
• Image Mode: Fusion, IR（default), PIP, Visual
• Digital Camera: 2MP
• Wireless: ✔
• PC-based Analysis Software: ✔
• Supports 13 languages (English by default)
• Laser Indicator: ✔
• Microphone: ✔
• Flash Shield: ✔
• Lens cap for protection: ✔
• Alloy Metal Base: ✔
• Razor X thermal technology: ✔
• Fresh rate: 25Hz
• FOV: 40°×30°
• IFOV: 2.79mrad
• Pixel Pitch: 12μm
• Focus Mode: Fixed focus
• Min Focus Distance:
• THOR001: 8cm
• THOR002: 30cm
• Fast Charge: 18W
• Battery: 5000mAh rechargeable lithium battery
• Charging Time: 4h
• Operating Time: 8h

4 Vision Modes

• Rivaling $3,000 thermal cameras, Thor brings pro-level inspection at a fraction of the cost.
• 4 advanced modes (IR, Visible, PIP, IR-Fuse™) deliver industrial diagnostic performance.

Features:

• Visual Light
• 2MP, clear structural reference for accurate inspection context.
• PIP
• Picture in Picture
• IR-Fuse™
• Dual-light fusion, blending visible and infrared imaging for clearer detection.
• Infrared(default)
• Full thermal view.

Macro Lens:

• Thor 001 with detachable macro lens (8 cm) inspects 0.25 mm components, revealing PCB faults, early HVAC issues, and heat patterns on industrial gear.

Other features:

Package Includes:
