SenseCAP ORCH S4 is an Air Temperature / Humidity / Atmospheric Pressure / Light four-in-one weather instrument featuring solid performance, ultra-low power consumption, and easy installation. It integrates 4 sensors monitoring parameters of air temperature, humidity, barometric pressure, and light intensity. With strong robustness, it is particularly suitable to operate in severe environments both indoor and outdoor. This version (A1B) comes with a waterproof aviation connector, saving you time and efforts in connecting the sensor to a data logger with hook-up wires and screws.

Features:

Solid Performance: high reliability, superior stability, and ultra-low power consumption
Compact Size: air temperature, humidity, barometric pressure, and light all in one
Universal Protocols: MODBUS RS-485 or SDI-12
Wide Range Power Supply: 3.6V ~ 16V
Strong Robustness: IP66 enclosure, suitable for outdoor applications and extremely complicated environment
User-friendly: with build-in data pre-processing, easy to use, integrate and install

Specifications:

MODBUS RS-485:
Power Supply	3.6V ~ 16V
Current Consumption	Vin=16V: 3.6mA (typical)
	Vin=12V: 4.7mA (typical)
	Vin=5V: 11.0mA (typical)
	Vin=3.6V: 14.5mA (typical)
Warm-up Time	250ms (typical)
Scan Interval	1s
Poll Rate	1Hz
Response Time	≤ 4ms
General Parameters:
Product Model	SenseCAP ORCH S4 (A1B)
Power Supply	3.6 ~ 16V
Protocol	MODBUS-RTU RS485/ MODBUS-ASCII RS485/ SDI-12 (v1.4)
IP Rating	IP66 (water-proof box)；IPX5 (solar radiation shield)
Operating Temperature	-40 ℃~ +65 ℃
Operating Humidity	0 ~ 100 %RH （non-condensing)
Barometric Pressure:
Parameters	Condition	Value
Range	-	300-1100 hPa
Resolution	-	1 Pa
Relative Accuracy	700 to 900 hPa, 25 to 40 °C	±0.12 hPa
Absolutely Accuracy	300 to 1100 hPa, -20 to 0 °C	±1.7 hPa
Absolutely Accuracy	300 to 1100 hPa, 0 to 65 °C	±1.0 hPa
Temperature Coefficient Offset	900 hPa, 25 to 40 °C	1.5 Pa/K
Drift	-	±1.0 hPa/year
Air Temperature:
Range	-40 °C to +85 °C
Accuracy	±0.2 °C
Resolution	0.1 °C
Drift	< 0.03 °C /year
Air Humidity:
Range	0 to 100 %RH
Accuracy	±1.5 %RH
Resolution	1 %RH
Drift	< 0.25 %RH/year
Light Intensity:
Range	0 to 188000 Lux
Accuracy	±1.5%
Resolution	0.045 Lux

Applications:

Smart Agriculture
Greenhouse
Smart Industry
Smart Cities
Environmental Monitoring
Other IoT Sensor Applications

Documents:

Warranty: 12 months

Warranty will not apply if Product fails or is damaged after delivery to you due to accident, abuse or misuse.

Package Includes:

1 x SenseCAP ORCH S4 4-In-1 Weather Sensors (A1B), Air Temperature/Humidity/Atmospheric Pressure/Light - with waterproof aviation connector

SenseCAP ORCH S4 4-In-1 Weather Sensors (A1B) - with waterproof aviation connector

Brand: Seeed Studio
Product Code:Seeed-SenseCAP-Weather
