Light Ranger 4 click is an accurate distance measurement Click board™ based on a ToF (Time of Flight) measurement principle. The FlightSense™ enabled VL53L1X rangefinder module from STMicroelectronics is a complete measurement stack on the chip. It is surprisingly easy to work with, as this highly integrated range finder module exposes only I2C interface, XSH and INT pins to the host controller. It features the invisible Class1 laser emitter, used to emit a narrow band of a harmless modulated light beam in the IR range (940 nm), physical infrared filters and optics to achieve the best ranging performance in various ambient lighting conditions with a range of cover window options. It can measure distances up to 4000mm, with up to 50 Hz ranging frequency.

Specifications:

Range: up to 4000 mm
Frequency: up to 50 Hz
Laser: Class 1 emitter 940 nm
Interface: I2C
Compatibility: mikroBUS
Click board size:M (42.9 x 25.4 mm)
Input Voltage: 3.3V or 5V
Weight: 18g

Applications:

Counting dimensions of goods in industry
Controlling a safety area
Contactless digital measurement tools
3D visual guidance applications in robotics

Package Includes:

1 x LightRanger 4 click

LightRanger 4 click

Brand: Mikroe
Product Code:Plx-light-Ranger-4-Click
Reward Points:39
Availability:In Stock

रo 4,564.24
Ex Tax:रo 3,868.00
Price in reward points:3868
4 or more रo 4,527.66
8 or more रo 4,491.08
20 or more रo 4,454.50
40 or more रo 4,419.10

Qty

0 reviews / Write a review
