Soil moisture is the water stored in the soil. Too much moisture in the soil is not only bad for the plants but also wastes water and adds extra burdens to our planet earth. Soil temperature is the warmth of the soil. Plants grow best at their preferred temperature ranges. With access to soil moisture and temperature data, we can take actions to make sure the right amount of water is irrigated at the appropriate time, and the plants are in optimal environments which are good for their growth.

This Soil Moisture & Temperature Sensor MODBUS-RTU RS485 (S-Soil MT-02A) is designed with industry standards. It incorporates two sensors (soil moistures sensor and soil temperature sensor) into one, featuring high precision and high sensitivity. By measuring the dielectric constant of the soil, it can stably measure the soil VWC (volumetric water content) regardless of various soil types. The measurement conforms to current international standards for soil moisture measurement.

This soil sensor is IP68 rated, very robust and durable, suitable to be applied at long-term monitoring of soil moisture and temperature at scientific experiments, water-saving irrigation, greenhouses, outdoor farming, gardening, precision agriculture, and other professional environmental monitoring scenarios.

Features:

High Performance: high accuracy, reliability, and stability
Universal Protocol: MODBUS-RTU RS485
Wide range power supply: 3.6V ~ 30V
Industrial-grade Robustness: IP68 rated, suitable for long-term applications
Strong Anti-interference: made of flame-retardant epoxy resin
High Durability: anti-corrosion, with excellent performance for long-term use
User-friendly: easy to use, install and integrate
Safety: designed with reverse voltage protection

Specifications:

General Parameters
Product Model	S-Soil MT-02A
Interface	RS-485
Protocol	MODBUS-RTU RS485
Power Supply	3.6 ~ 30V DC
Current Consumption	Max 40mA@24V DC
Operating Temperature	-40℃ ~ +85℃
Storage Temperature	-40℃ ~ +85℃
Response Time	< 1 second
Measuring Area	A cylinder area(with the probe as the center, diameter: 7cm, height: 7cm)
Probe Material	Food-grade stainless steel
Seal Material	Black flame-retardant epoxy resin
IP Rating	IP68
Cable Length	5 meters
Installation	All buried or probe into the media to be measured
Device Weight	270g

Soil Temperature
Range	-40℃ ~ +80℃
Accuracy	± 0.5 ℃
Resolution	0.1℃

Soil Moisture
Range	From completely dry to fully saturated (from 0% to 100% of saturation)
Accuracy	±3% (0~53%) ±5% (53~100%)
Resolution	1%

Soil Moisture

Range

From completely dry to fully saturated

(from 0% to 100% of saturation)

Accuracy

±3% (0~53%)

±5% (53~100%)

Resolution

Applications:

Water-saving irrigation
Scientific Experiments
Greenhouse Management
Horticulture and Gardening
Golf turf Management
Smart Agriculture
Other Environmental Monitoring Scenarios

Documents:

ECCN/HTS:

HSCODE 9025800000

Package Includes:

1 x Industrial Soil Moisture & Temperature Sensor MODBUS-RTU RS485 (S-Soil MT-02A)
