The LIS2DW12 is a low power high-performance three-axis linear accelerometer, featuring low power(50nA), low noise(1.3mgRMS), 32 FIFO, ±2g/±4g/±8g/±16g full scale, 16-bit data output, and 1.6~1.6KHz bandwidth. The sensor comes with two independent programmable interrupts and a dedicated internal engine that can achieve various motion and acceleration detection including free-fall, portrait/landscape detection, 6D/4D orientation detection, configurable single/double-tap recognition, stationary/motion detection, wakeup for smart power saving, etc. And for your convenience, we provide you with sample programs(C and Python) for the above functions.

Features:

Selectable scales: ±2g/±4g/±8g/±16g
16-bit data output
Two independent programmable interrupts
Dedicated internal engine for achieving various functions: free-fall, portrait/landscape detection, 6D/4D orientation detection, configurable single/double-tap recognition, stationary/motion detection, wakeup for smart power saving, etc.

Specifications:

Operating Voltage: 3.3V
Operating Current: 50nA (low power consumption mode)/0.17mA (high performance mode)
Interface: SPI/I2C
I2C Address: 0x19(default address)/0x18(optional: pull down the SDO pin to select)
Optional Scale: ±2g/±4g/±8g/±16g
Operating Temperature: -40℃~+85℃
16-Bit Data Output
Frequency: 1.6Hz~1600Hz
Ultra-low Noise: 1.3 mg RMS (low power mode)
32-level FIFO (first-in first-out buffer zone)
10000g high shock survivability
ECOPACK, RoHS and “Green” compliant
Module size: 15 x 20 (mm) / 0.59 x 0.79 (inch)
