Supercapacitors have characteristics ranging from traditional capacitors and batteries. As a result, supercapacitors can be used like a secondary battery when applied in a DC circuit. These devices are best suited for use in low voltage DC hold-up applications such as embedded microprocessor systems with flash memory.
HV Series Supercapacitors, also known as Electric DoubleLayer Capacitors (EDLCs), are intended for high energy storage applications.
Features:
- Wide range of temperature from −25°C to +60°C and −25°C to +70°C
- Maintenance free
- Maximum operating voltages of 2.5 and 2.7 VDC
- Highly reliable against liquid leakage
- Lead-free and RoHS compliant
Specifications:
| Capacitance | 22F |
| Capacitance Tolerance | 30% |
| Voltage DC | 2.7 VDC |
| Temperature Range | -25/+60°C |
| Rated Temperature | 60°C |
| Resistance | 100 mOhms (1kHz) |
| Discharge Current | 18 mAmps (30 Minutes After Charging) |
Dimensions:
| D | 12.5mm +/-0.5mm |
| L | 35mm +/-2mm |
| S | 5mm +/-0.5mm |
| LL Negative | 15mm MIN |
| LL Positive | 20mm MIN |
| F | 0.6mm NOM |
Documents:
Package Includes:
- 1 x Electric Double Layer Super Capacitor HVZ0E226NF - 2.7 VDC, -25/+60°C
WhatsApp
Electric Double Layer Super Capacitor HVZ0E226NF - 22F, 2.7 VDC, -25/+60°C
- Product Code: :ARO-HV-22F-SuperCap
- Reward Points: :5
- Availability: :In Stock
-
रo 510.53
- Price in reward points: 511
-
- 30 or more रo 507.38
- 55 or more रo 503.15
- 140 or more रo 498.95
- 280 or more रo 494.73
