Features:

Note:

• The initial production batch uses the AM6232 processor as designed. For enhanced performance in mass production, we have upgraded to the AM6254 processor. During this transition, devices with AM6232 or AM6254 may be shipped randomly.
• High-Performance Dual-Core Processing: Now powered by the AM6254 SoC, featuring dual ARM Cortex-A53 cores up to 1.4 GHz (higher performance), with 512 MB LPDDR4 SDRAM running at 3200 MHz and a microSD card slot for flexible storage.
• Advanced Real-Time Control：A single-core ARM Cortex-M4F MCU running at up to 400 MHz and a dual-core Programmable Real-Time Unit Subsystem (PRUSS) at 333 MHz enable precise real-time control and automation, making it ideal for time-sensitive applications.
• Pocket-Size with Rich Peripherals：55 x 35 mm compact size and 72 expansion pin headers with power and battery I/Os, high-speed USB, 8 analog inputs, 52 digital I/Os, and numerous digital interface peripherals. One dedicated MSPM0L1105 Arm Cortex-M0+ MCU for 12-bit ADC.
• Power Management System：The TPS6521903 PMIC combines system-level power management optimization with BQ21040 to support intelligent charging of single-cell Li-Ion and Li-Polymer batteries, enabling seamless power switching and facilitating space-limited portable applications.

Specifications:

• Parameters : Description
• Processor : TI AM6254 – Dual ARM Cortex-A53 cores @ 1.4 GHz
• TI AM6254 – ARM Cortex-M4F core @ 400 MHz
• SDRAM Memory : 512MB DDR4 3200 MHz
• PMIC : TPS6521903
• Indicators : 1 x Power
• 1 x Battery charging
• 4 x User Controllable LEDs
• Interfaces : 72 × GPIO
• Buttons : 1 User/Boot Button
• 1 Power button
• Debug Support : 3 pin 3.3V JST-SH 1.00mm UART debug port (RPI debug probe compatible)
• 10-pin JTAG TAG-CONNECT footprint
• Power Source : USB C or Cape Header VIN (5V @ 1A)
• SD/MMC Connector : microSD (1.8/3.3V)
• Dimensions : 55 x 35 mm

Hardware Overview

Onboard

PinOut:

Applications:

• Industrial automation
• Robotics
• Internet of Things (IoT)
• Embedded teaching
• Home automation
• Edge computing

Documentations:

• BeagleBoard PocketBeagle 2 Documentation

Package Includes:

• 1 x BeagleBoard PocketBeagle 2
• 1 x Getting Started Guide
